2412TZ Receiver optical fiber devices, combined with 1414XX and 850nm multi-mode optical fiber, provide high performance and low cost optical fiber communication links for industrial, power generation, medical, transportation, and game applications.

The 1414XX is driven by 60 mA current with a minimum transmission distance of 2500meters.

The 2412 TZ Series supports industrial standard ST fiber ports with threaded options.

2412 For a variety of fiber core diameter, including 50/125μm,62.5/125μm, 100 / 140μm and 200μm.

The 2412 TZ series is a receiver, consisting of a high-gain span resistance amplifier with an integrated photodiode.

The output stage is an open-leakage MOSFET structure.

 Product Features

   - Data transfer rate: DC-5MBd

   - Minimum transmission distance: 2500 m

   - The output waveform pulse width is stable

   - Compliance the RoHS criteria

   - Power supply support is + 5V

   - ST connector with thread

   - Operating temperature range (Industrial： -40°C to +85°C)
