1414TZ transmitter optical fiber devices,combined with 850nm multimode optical fiber, provide high performance and low cost optical fiber communication links for industrial, power generation, medical, transportation, and game applications.

1414TZ is driven by 60 mA current with a minimum transmission distance of 2500 meters.

The 1414TZ Series supports industrial standard ST fiber ports with threaded option.

The 1414 TZ series fits multiple modes of fibers with fiber core diameter, including 50/125μm,62.5/125μm, 100 / 140μm and 200μm.

The 1414TZ is a transmitter, packaged of a high power LED chip with wavelength of 850nm. The 850nm multi-mode fiber with 62.5/125um core diameter output an optical power typical value of-13.5dBm driven by 60 mA current.

 Product Features

   - Data transfer rate: DC-50 MBd, up to 160 MBd

   - Minimum transmission distance: 2500 m

   - The output waveform pulse width is stable

   - Compliance the RoHS criteria

   - Power supply support is + 5V

   - ST connector with thread

   - Operating temperature range (Industrial： -40°C to +85°C)
